Schneider Electric 140CPS12420 Module The Modicon 140CPS12420 is a power supply module manufactured by Schneider Electric for the Modicon Quantum automation platform. It is a 115 V/230 V AC – redundant module. It is a safety module made for use in a Quantum Safety PLC. It is certified for use in SIL 3 applications.

The Quantum power supply has a unique purpose. It is there to administer power to the system rack, and it is also present for squelching noise that would violate the system. In a place where voltage can fluctuate and have surged, it also protects your system from possible overvoltage. The environmental conditions where this module functions can have electrical noise interference; these units can operate without external isolation transformers.

SCHNEIDER Module.png

Schneider Electric 140CPS12420 Power Supply Module

Main
range of product	Modicon Quantum automation platform
product or component type	Power supply module
power supply type	Redundant

Complementary
input voltage	115 V (93...138 V) AC 47…63 Hz 230 V (170...276 V) AC
input current	1100 mA at 115 V 600 mA at 230 V
inrush current	19 A 230 V 38 A 115 V
Rated power in VA	130 VA
associated fuse rating	2 A, slow-blow
Harmonic distortion	<= 10 % of fundamental rms value
output voltage	5.1 V DC
power supply output current	11 A 60 °C standalone 10 A 60 °C redundant
output overvoltage protection	Internal
output overload protection	Internal
power dissipation	6 + (1.5 x Iout) where Iout is in A
alarm output	1 NC 6 A 220 V power supply fault
local signalling	1 LED (green) for power (PWR OK)
Marking	CE
module format	Standard
Net weight	0.65 kg

Environment
Standards	UL 508 CSA C22.2 No 142
product certifications	CUL
resistance to electrostatic discharge	4 kV contact conforming to IEC 801-2 8 kV on air conforming to IEC 801-2
resistance to electromagnetic fields	10 V/m 80…2000 MHz conforming to IEC 801-3
Ambient air temperature for operation	0…60 °C
Ambient air temperature for storage	-40…85 °C
relative humidity	95 % without condensation
Operating altitude	<= 5000 m

Packing Units
Unit Type of Package 1	PCE
Number of Units in Package 1	1
Package 1 Height	5.1 cm
Package 1 Width	17.2 cm
Package 1 Length	31.8 cm
Package 1 Weight	753 g
Unit Type of Package 2	S03
Number of Units in Package 2	7
Package 2 Height	30 cm
Package 2 Width	30 cm
Package 2 Length	40 cm
Package 2 Weight	5771 g
