REXROTH 4WE6Y62/EG24N9K4 R900561276 + HSZ10-26916-AA/G24N9K4M01 R901025684,

part number R900561276. The valve is a directional spool valve, symbol Y, with electrical solenoid and a 24V DC power supply. The valve has a maximum flow rate of 60L/min and a maximum operating pressure of 350 bar [0].

The valve is available for purchase from Bosch Rexroth and typically ships in 20 working days from Bethlehem, US. There are 7 in stock at the time of writing [1]. The valve is available in size 6 with symbol Y and electrical solenoid with a 24V DC power supply

The valve has a model number of 4WE 6 Y6X/EG24N9K4 [3]. The valve is a 4/3-, 4/2- or 3/2-way valve with a porting pattern according to ISO 4401-03-02-0-05 (with or without locating hole). The valve has a high-power solenoid, which can optionally be rotated by 90°. The valve has an electric connection as single or central connection. The valve has optional auxiliary operating device and spool position monitoring. The valve is optionally CE conform according to the Low-Voltage Directive 2014/35/EU for electrical voltages >50 VAC or >75VDC. The solenoid coil can be approved with UR marking according to UL 906, edition 1982, and can be approved according to CSA C22.2 no. 139-1982. The valve has various electrical connections, including individual and central connections, with different types of connectors available. The valve can be operated with a DC voltage or an alternating voltage. The valve has a concealed manual override "N9" (standard), and a manual override "mushroom button" (large), not lockable "N6"

• Manufacturer : Rexroth

• Product No. : R900561278

• Product type : 4WE6E6X/EG24N9K4 Directional Spool Valve Bosch

• 4 = 4 main ports

• 6 = NG 6, ISO4401-3, NFPA/ANSI D03 Interface

• E = Spool symbols

• 6X = Component series 60 to 69 (60 to 69: unchanged installation and connection dimensions)

• E = Heavy-duty solenoid wet-pin with removeable coil

• G24 = 24 V DC

• N9 = With concealed manual override (standard)

• K4 = Individual connection : Without mating connector with connector as per DIN EN 175301-803

• Seal material : V = FKM seals

• Ambient temperature range °C [°F] : –30 to +50 [–22 to +122] (NBR seals), –20 to +50 [–4 to +122] (FKM seals).

• Shipping Weight : 3 Kg
