Bently 3500/91-01-01（161204-01+161216-01）| 3500/91M  EGD Communication Gateway

3500/91M-AXX-BXX

 A: I/O Module Type

   01 Ethernet 10BASE-T/100BASE-TX I/O Module

 B: Agency Approval Option

   00 None

   01 CSA/NRTL/C

   02 CSA/ATEX/IECEx

The Bently 3500/91-01-01 (also known as 3500/91M EGD Communication Gateway) is a module designed to provide comprehensive communication capabilities for 3500 rack-monitored values and status. It uses an Ethernet network path to provide information with response times suitable for controller applications 2, 5.

Key features of the module include:

Support for EGD (version 2.01) and Ethernet UDP/IP protocols.

The module supports IEEE802.3 for 10BASE-T and 100BASE-TX (twisted pair) Ethernet standards.

Power consumption is typically around 7.4 watts.

It can handle producer exchanges such as rack, module, channel, and data value status; data values (float); setpoints (float).

It also supports consumer exchanges like group reset, group trip multiply, group alarm inhibit, and group special alarm inhibit 2, 5.

The physical dimensions of the main module are 241.3 mm x 24.4 mm x 241.8 mm (9.50 in x 0.96 in x 9.52 in) and weighs 0.79 kg (1.75 lbs.). The I/O module dimensions are 241.3 mm x 24.4 mm x 99.1 mm (9.50 in x 0.96 in x 3.90 in) and weighs 0.39 kg (0.85 lb.)
